[cam.in.head]

hi .could some kind person please post a picture of an elite rear shelf saloon from the top and underneath please .i wish to install some  speakers instead of the rear
door speakers which serve no real purpose !
just to see the factory position
cheers

[TheBoy]

Not sure I have photo, but you can see from the boot where they bolt to the metal part under parcel shelf

[cam.in.head]

yes ive seen that now .even the brochure doesnt realy show the top in any detail regards the speaker grille .(or is it where the air vent grille already is ? )
thankyou for reply

[BazaJT]

From memory the two parcel shelf speakers in the Elite saloon are subs and are one each side of the rear window blind.At present I'm having problems logging onto the forum with my mobile phone but once that's resolved I'll pop to my lock up and take the pictures you want and send them on,unless of course someone's already done it by then.

[johnnydog]

hi .could some kind person please post a picture of an elite rear shelf saloon from the top and underneath please .i wish to install some  speakers instead of the rear
door speakers which serve no real purpose !
just to see the factory position
cheers

I can take some photos of mine in the morning Chris, but putting photos on here is something that I've never been able to master (other forums I contribute to are straight forward!), so I will have to email or text them to you

[cam.in.head]

email is fine john .as my last message to you .
just to get an idea of how the factory ones look .cheers

[johnnydog]



email is fine john .as my last message to you .
just to get an idea of how the factory ones look .cheers


Sorry Chris, only just seen your email

[TheBoy]

For the carpet bit of the rear parcel shelf, assuming using the same sized speakers as the Bose woofers, using an Elite parcel shel is probably the easiest option.  Although there seems to be far fewer of them being broken now...

[johnnydog]

email is fine john .as my last message to you .
just to get an idea of how the factory ones look .cheers

Email sent Chris with pics

[cam.in.head]

thankyou .pictures received from mr johhnydog.
yes if someone had a pair of bose grilles that would be good (althou i would probably remove the logo as ive bever realy rated bose stuff itself!)
will be looking at the area today

[cam.in.head]

ok thanks everybody.
ive had a good look and it would seen the easiest option is to take a scrapyard trip and find some grilles in a similar style (or some oe ones .)the holes need to be cut  as theyre just blank areas underneath.deprnding on what speakers i put in ..probably have to blank off some of the air exit or baffle the soeakers as the metal shelf is heavily perforated .

[cam.in.head]

found the wires for the rear door speajers and recconnected and brought through ready for fitting .just need the grills now before i cut any holes .have put a wanted ad on here and messaged a coulple of ebay sellers .

[Valentin]

You mean you found the wires pre installed near the shelf ?

[cam.in.head]

no i found the wires that went to the rear door speakers and brought them through to the boot .
i never even considered there might be wires there as i assumed the bose wiring would be different anyway . wires are now in and ready anyway !
